dual spindle swiss-type lathe sz-125en2
产品型号：sz-125en2
产品特点
●the spindle system of the machine tool continues the hidden motorized spindle. the integrated motorized spindle has the characteristics of high speed, high precision, low noise,
low temperature rise, small volume and simple installation.
●the standard transverse tool arrangement structure, reasonable and compact tool layout, flexible tool configuration, high rigidity body structure make the machine with high stability,
high speed and high precision, high compound and other advantages, to provide customers with high efficiency turning, milling compound processing capacity.
●it is used to process slender shaft parts with diameter of 2mm-12mm(especially suitable for 2mm-8mm) with many varieties and small batches, complex structure, high precision
requirements, and need to shorten the production cycle.
low temperature rise, small volume and simple installation.
●the standard transverse tool arrangement structure, reasonable and compact tool layout, flexible tool configuration, high rigidity body structure make the machine with high stability,
high speed and high precision, high compound and other advantages, to provide customers with high efficiency turning, milling compound processing capacity.
●it is used to process slender shaft parts with diameter of 2mm-12mm(especially suitable for 2mm-8mm) with many varieties and small batches, complex structure, high precision
requirements, and need to shorten the production cycle.
产品详情
加工应用：
医疗器械、五金工具、纺织机械、电子通信、航空航天等
结构配置（功能扩展）：
| model | sz-125en1 5 axis, dual spindle | sz-125en2 5 axis, dual spindle | |||
| cutting-tool layout sketch |  |  | |||
| nc device | mitsubishi m80 | mitsubishi m80 | |||
| power source | 220vac | 220vac | |||
| lathe rated power | kw | 11 | 11 | ||
| machining range | max machining dia. | mm | φ12 | φ12 | |
| main spindle max clamping dia. | mm | φ12 | φ12 | ||
| max feed length (once) | mm | max 205 | max 205 | ||
| main/sub spindle | main spindle power | kw | 1.5/2.2 | 1.5/2.2 | |
| sub spindle power | kw | 1.5/2.2 | 1.5/2.2 | ||
| main spindle max through hole dia. | mm | max φ13 | max φ13 | ||
| c axis resolution | ° | c1/c2 0.001° | c1/c2 0.001° | ||
| main/sub spindle rev speed | rpm | max12000/12000 | max12000/12000 | ||
| sub spindle max clamping dia. | mm | max φ12 | max φ12 | ||
| sub spindle max through hole dia. | mm | max φ13 | max φ13 | ||
| main spindle max travel | with guide bush | mm | 205 | 205 | |
| non guide bush | mm | 308 | 308 | ||
| max tool installed qty. | pcs | 20 | 20 | ||
| od turning tool | qty.×model | 7×□10 | 7×□10 | ||
| cross live tool | qty.×model | 5×er11 | 5×er11 | ||
| drilling dia. | mm | max φ7 | max φ7 | ||
| tapping/threading die dia. | max m6 | max m6 | |||
| live tool rev speed | rpm | max 5000 | max 5000 | ||
| live tool power | kw | 1 | 1 | ||
| end-face tool （main spindle） | fixed | qty.×model | 4×er16 | 4×er16 | |
| drilling dia. | mm | max φ10 | max φ10 | ||
| tapping/threading die dia. | max m8 | max m8 | |||
| live | qty.×model | - | - | ||
| drilling dia. | mm | - | - | ||
| tapping/threading die dia. | - | - | |||
live tool rev speed | rpm | - | - | ||
| live tool power | kw | - | - | ||
| back end-face tool （sub spindle） | fixed | qty.×model | 4×er16 | - | |
| drilling dia. | mm | max φ10 | - | ||
| tapping/threading die dia. | max m8 | - | |||
| live | qty.×model | - | *4×er16 | ||
| drilling dia. | mm | - | max φ8 | ||
| tapping/threading die dia. | - | max m6 | |||
| live tool rev speed | rpm | - | max 5000 | ||
| live tool power | kw | - | 1.0 | ||
| rapid feed speed | m/min | 30(z1/z2/x2/y) 15(x1) | 30(z1/z2/x2/y) 15(x1) | ||
| feed motor power | kw | 1.0(z1/z2/x1/x2/y) | 1.0(z1/z2/x1/x2/y) | ||
| cutting oil pump power | kw | 0.4 | 0.4 | ||
| main/sub spindle cooling oil pump power | kw | 0.12 | 0.12 | ||
| lubricating oil pump power | kw | 0.004 | 0.004 | ||
| max collecting length of workpieces collect box | mm | 80 | 80 | ||
| main/sub spindle center to the bottom of lathe body | mm | 990 | 990 | ||
| cutting oil tank volume | l | 160 | 160 | ||
| net weight | kg | 2500 | 2500 | ||
| dimensions(l×w×h) | mm | 2068×1210×1698 | 2068×1210×1698 | ||
notes :
1.od turning tool length : 125mm
2.*4×er16: standard 2 live and 2 fixed tool holder (option: 4 live tool holder)
technical parameters are subject to change without prior notice.
| 12series | ||
| op system | syntec 22tb/220tb | fanuc oi-tf plus |
| power source | 380vac | 200vac |
| live tool power | 1kw | 0.75kw |
| live tool rev speed | 5000rpm | 4000rpm |
| feed motor power | 1.0kw(z1/z2/x1/x2/y) | 0.75kw(z1/z2/x1/x2/y) |
| rapid feed speed | 30(z1/z2/x2/y) 24(x1) | 30(z1/z2/x2/y) 24(x1) |
standard configuration
1. taiwan syntec control system
2. 10.4 inch color lcd display
3. main/sub spindle cooling system
4. lricating system
5. rotatory guide bush
6. main/sub spindle air blowing device
7. main/sub spindle air blowing device
8. electric leakage protection
9. transformer
10. external light connector
11. 3-colour tower light
12. hiwin/pmi screw/guide rail, class 3
13. cutting oil tank
14. main/sub spindle collet 1pcs; guide bush 1 pcs
15. tool cabinet
1. taiwan syntec control system
2. 10.4 inch color lcd display
3. main/sub spindle cooling system
4. lricating system
5. rotatory guide bush
6. main/sub spindle air blowing device
7. main/sub spindle air blowing device
8. electric leakage protection
9. transformer
10. external light connector
11. 3-colour tower light
12. hiwin/pmi screw/guide rail, class 3
13. cutting oil tank
14. main/sub spindle collet 1pcs; guide bush 1 pcs
15. tool cabinet
optional configuration
1.automatic bar feeder
2. chip conveyor
3. oil mist collector
4. high pressure pump
5. long workpiece collector
6. workpiece belt conveyor
7. xternal working litht
8. electric leakage protection
9. cut-off tool breakage detector
10. special shaped material clamping device
11.automatic fire extinguisher
1.automatic bar feeder
2. chip conveyor
3. oil mist collector
4. high pressure pump
5. long workpiece collector
6. workpiece belt conveyor
7. xternal working litht
8. electric leakage protection
9. cut-off tool breakage detector
10. special shaped material clamping device
11.automatic fire extinguisher
