single spindle swiss-type lathe sz-20c3
产品型号：sz-20c3
产品特点
● standard three axis swiss-type single spindle lathe, stable performance, large market holding, high cost performance.
● adopt high precision c3 grinding ball screw,p grade precision guide rail, express moving speed up to 30m/min.
● equipped with independent research and development of air cooled motorized spindle, internal use of high precision p4 class angular contact ball bearings, to ensure rigidity, accuracy and thermal stability.
● horizontal tool arrangement, easy chip removal, high rigidity of tool holder.
● support turning/milling/drilling/tapping/engraving, can complete a variety of complex parts processing.
● spline shaft synchronous guide bush mode, a feeding length of 240mm, to ensure the long shaft parts precision stability.
● adopt high precision c3 grinding ball screw,p grade precision guide rail, express moving speed up to 30m/min.
● equipped with independent research and development of air cooled motorized spindle, internal use of high precision p4 class angular contact ball bearings, to ensure rigidity, accuracy and thermal stability.
● horizontal tool arrangement, easy chip removal, high rigidity of tool holder.
● support turning/milling/drilling/tapping/engraving, can complete a variety of complex parts processing.
● spline shaft synchronous guide bush mode, a feeding length of 240mm, to ensure the long shaft parts precision stability.
产品详情
加工应用：
医疗器械、五金工具、纺织机械、电子通信、航空航天等
结构配置（功能扩展）：
| model | sz-20c1 3 axis, single spindle | sz-20c2 3 axis, single spindle | sz-20c3 3 axis, single spindle | |||
cutting-tool layout sketch |  |  |  | |||
| nc device | mitsubishi e80 | mitsubishi e80 | mitsubishi e80 | |||
| power source | 200vac | 200vac | 200vac | |||
| lathe rated power | kw | 7 | 7 | 7 | ||
| machining range | max machining dia. | mm | φ20 | φ20 | φ20 | |
main spindle max clamping dia. | mm | φ20 | φ20 | φ20 | ||
max feed length (once) | mm | max 240 | max 240 | max 240 | ||
| main spindle | main spindle power | kw | 2.2 | 2.2 | 2.2 | |
main spindle max through hole dia. | mm | max φ21 | max φ21 | max φ21 | ||
c axis resolution | ° | c1 0.001° | c1 0.001° | c1 0.001° | ||
main spindle rev speed | rpm | max7000 | max7000 | max7000 | ||
main spindle max travel | with guide bush | mm | 240 | 240 | 240 | |
| max tool installed qty. | pcs | 11 | 14 | 16 | ||
| od turning tool | qty.×model | 7ר12 | 6ר12 | 6ר12 | ||
| cross live tool | qty.×model | - | 4×er16 | 4×er16 | ||
| drilling dia. | mm | - | max φ10 | max φ10 | ||
| tapping/threading die dia. | - | max m8 | max m8 | |||
live tool rev speed | rpm | - | max 5000 | max 5000 | ||
| live tool power | kw | - | 1 | 1 | ||
| end-face tool （main spindle） | fixed | qty.×model | 5×er16 | 4×er16 | 3×er16 | |
| drilling dia. | mm | max φ10 | max φ10 | max φ10 | ||
| tapping/threading die dia. | max m8 | max m8 | max m8 | |||
live | qty.×model | - | - | 3×er11 | ||
| drilling dia. | mm | - | - | max φ7 | ||
tapping/threading die dia. | - | - | max m6 | |||
live tool rev speed | rpm | - | - | max5000 | ||
| live tool power | kw | - | - | 0.4 | ||
rapid feed speed | m/mi | 30(z/y) 15(x) | 30(z/y) 15(x) | 30(z/y) 15(x) | ||
| feed motor power | kw | 1(z/x/y) | 1(z/x/y) | 1(z/x/y) | ||
| cutting oil pump power | kw | 0.35 | 0.35 | 0.35 | ||
| main spindle cooling fan power | kw | 0.04 | 0.04 | 0.04 | ||
| lubricating oil pump power | kw | 0.035 | 0.035 | 0.035 | ||
max collecting length of workpieces collect box | mm | 50 | 50 | 50 | ||
main/sub spindle center to the bottom of lathe body | mm | 955 | 955 | 955 | ||
| cutting oil tank volume | l | 120 | 120 | 120 | ||
| net weight | kg | 1700 | 1700 | 1700 | ||
| dimensions(l×w×h) | mm | 1716×1410×1560 | 1716×1410×1560 | 1716×1410×1560 | ||
notes: fanuc system
| 12c/20c series | ||
| op system | syntec 22tb | fanuc oi-tf plus |
| power source | 380vac | 200vac |
| live tool power | 1kw | 0.75kw |
| live tool rev speed | 5000rpm | 4000rpm |
| feed motor power | 1(z/x/y) | 0.75(z/x/y) |
| rapid feed speed | 30(z/y) 15(x) | 30(z/y) 15(x) |
