single spindle swiss-type lathe sz-12c2
产品型号：sz-12c2
产品特点
● standard three axis swiss-type single spindle lathe, stable performance, large market holding, high cost performance.
● adopt high precision c3 grinding ball screw,p grade precision guide rail, express moving speed up to 30m/min.
● equipped with independent research and development of air cooled motorized spindle, internal use of high precision p4 class angular contact ball bearings, to ensure rigidity, accuracy and thermal stability.
● horizontal tool arrangement, easy chip removal, high rigidity of tool holder.
● support turning/milling/drilling/tapping/engraving, can complete a variety of complex parts processing.
● spline shaft synchronous guide bush mode, a feeding length of 240mm, to ensure the long shaft parts precision stability.
● adopt high precision c3 grinding ball screw,p grade precision guide rail, express moving speed up to 30m/min.
● equipped with independent research and development of air cooled motorized spindle, internal use of high precision p4 class angular contact ball bearings, to ensure rigidity, accuracy and thermal stability.
● horizontal tool arrangement, easy chip removal, high rigidity of tool holder.
● support turning/milling/drilling/tapping/engraving, can complete a variety of complex parts processing.
● spline shaft synchronous guide bush mode, a feeding length of 240mm, to ensure the long shaft parts precision stability.
产品详情
加工应用：
医疗器械、五金工具、纺织机械、电子通信、航空航天等
结构配置（功能扩展）：
| model | sz-12c2 3 axis, single spindle | |||
| cutting-tool layout sketch |  | |||
| nc device | mitsubishi e80 | |||
| power source | 200vac | |||
| lathe rated power | kw | 7 | ||
| machining range | max machining dia. | mm | φ12 | |
| main spindle max clamping dia. | mm | φ12 | ||
| max feed length (once) | mm | max 120 | ||
| main spindle | main spindle power | kw | 1.5 | |
| main spindle max through hole dia. | mm | max φ12 | ||
| c axis resolution | ° | c1 0.001° | ||
| main spindle rev speed | rpm | max7000 | ||
main spindle max travel | with guide bush | mm | 120 | |
| max tool installed qty. | pcs | 14 | ||
| od turning tool | qty.×model | 6ר10 | ||
| cross live tool | qty.×model | 4×er11 | ||
| drilling dia. | mm | max φ7 | ||
| tapping/threading die dia. | max m6 | |||
| live tool rev speed | rpm | max 5000 | ||
| live tool power | kw | 1 | ||
| end-face tool（main spindle） | fixed | qty.×model | 4×er11 | |
| drilling dia. | mm | max φ7 | ||
| tapping/threading die dia. | max m6 | |||
| live | qty.×model | - | ||
| drilling dia. | mm | - | ||
| tapping/threading die dia. | - | |||
| live tool rev speed | rpm | - | ||
| live tool power | kw | - | ||
| feed motor power | kw | 1(z/x/y) | ||
| cutting oil pump power | kw | 0.35 | ||
| main spindle cooling fan power | kw | 0.04 | ||
| lubricating oil pump power | kw | 0.035 | ||
| max collecting length of workpieces collect box | mm | 50 | ||
| main/sub spindle center to the bottom of lathe body | mm | 955 | ||
| cutting oil tank volume | l | 120 | ||
| net weight | kg | 1600 | ||
| dimensions(l×w×h) | mm | 1716×1410×1560 | ||
notes: fanuc system
| 12c/20c series | ||
| op system | syntec 22tb | fanuc oi-tf plus |
| power source | 380vac | 200vac |
| live tool power | 1kw | 0.75kw |
| live tool rev speed | 5000rpm | 4000rpm |
| feed motor power | 1(z/x/y) | 0.75(z/x/y) |
| rapid feed speed | 30(z/y) 15(x) | 30(z/y) 15(x) |
standard configuration
1. taiwan syntec control system
2. 10.4 inch color lcd display
3. main/sub spindle cooling system
4. lricating system
5. rotatory guide bush
6. main/sub spindle air blowing device
7. main/sub spindle air blowing device
8. electric leakage protection
9. transformer
10. external light connector
11. 3-colour tower light
12. hiwin/pmi screw/guide rail, class 3
13. cutting oil tank
14. main/sub spindle collet 1pcs; guide bush 1 pcs
15. tool cabinet
1. taiwan syntec control system
2. 10.4 inch color lcd display
3. main/sub spindle cooling system
4. lricating system
5. rotatory guide bush
6. main/sub spindle air blowing device
7. main/sub spindle air blowing device
8. electric leakage protection
9. transformer
10. external light connector
11. 3-colour tower light
12. hiwin/pmi screw/guide rail, class 3
13. cutting oil tank
14. main/sub spindle collet 1pcs; guide bush 1 pcs
15. tool cabinet
optional configuration
1.automatic bar feeder
2. chip conveyor
3. oil mist collector
4. high pressure pump
5. long workpiece collector
6. workpiece belt conveyor
7. xternal working litht
8. electric leakage protection
9. cut-off tool breakage detector
10. special shaped material clamping device
11.automatic fire extinguisher
1.automatic bar feeder
2. chip conveyor
3. oil mist collector
4. high pressure pump
5. long workpiece collector
6. workpiece belt conveyor
7. xternal working litht
8. electric leakage protection
9. cut-off tool breakage detector
10. special shaped material clamping device
11.automatic fire extinguisher
