standard sz-387f lathe
sz-387f cnc swiss type automatic lathe technical specifications | |||
nc device | fanuc 0i-tf plus | ||
power source | 200vac | ||
lathe rated power | kw | 20 | |
machining range | machining range dia. | mm | φ38 |
main spindle max clamping dia. | mm | φ38 | |
max feed length (once) | mm | max 320 | |
main/sub spindle | main spindle power | kw | 5.5/7.5 |
sub spindle power | kw | 3.7/5.5 | |
main spindle max through hole dia. | mm | max φ39 | |
c axis resolution | ° | c1/c2 0.001° | |
main/sub spindle rev speed | rpm | max 6000 | |
sub spindle max clamping dia. | mm | max φ38 | |
sub spindle max through hole dia. | mm | max φ39 | |
main spindle max travel | with guide bush | mm | 320 |
non guide bush | mm | 80 | |
max tool installed qty. | pcs | 35 | |
od turning tool | qty.×model | 4×口16 1×口20 | |
cross live tool | qty.×model | 5×er16 | |
drilling dia. | mm | max φ10 | |
tapping/threading die dia. | max m8 | ||
live tool rev speed | rpm | max 4500 | |
live tool power | kw | 1.2 | |
end-face tool (main spindle) | fixed | qty.×model | 4×er16 | ||
drilling dia. | mm | max φ10 | |||
tapping/threading die dia. | max m8 | ||||
end face tool b axis (main spindle) | live tool qty.×model | front：4×er16 back：4×er11 | |||
drilling dia. | mm | φ10 | |||
tapping/threading die dia. | m6 | ||||
live tool rev speed | rpm | max 5000 | |||
live tool power | kw | 1.0 | |||
rotation angle | ° | 0°~150° | |||
rotation accuracy(arcsecond) | ″ | 0.1 | |||
back end-face tool (sub spindle) | fixed | qty.×model | 4×er16 | ||
drilling dia. | mm | max φ10 | |||
tapping/threading die dia. | max m8 | ||||
live | back end face tool | qty.×model | 4×er16 | ||
back end face cross live tool | qty.×model | 4×er16 | |||
drilling dia. | max φ10 | ||||
tapping/threading die dia. | max m8 | ||||
live tool rev speed | max 4500 | ||||
live tool power | 1.2 | ||||
od turning tool | 4×□12 | ||||
rapid feed speed | m/min | 24(z1/z2/x2/x1/y1/y2) | |||
feed motor power | kw | 1.2(z1/z2/x1/x2/y1/y2) | |||
x,y,z positioning accuracy | mm | 0.005 | |||
x,y,z repeatability | mm | 0.005 | |||
cutting oil pump power | kw | 0.4 | |||
main/sub spindle cooling oil pump power | kw | 1.2 | |||
lubricating oil pump power | kw | 0.25 | |||
max collecting length of workpieces collect box | mm | 80 | |||
main/sub spindle center to the bottom of lathe body | mm | 1100 | |||
cutting oil tank volume | l | 190 | |||
air source pressure | mpa | ≧0.5 | |||
net weight | kg | 5000 | |||
dimensions(l×w×h) | mm | 2850×1600×2060 | |||
